Stanko LA760x3000 Manual Lathe

STANKO LA760 × 3000

The STANKO LA760 × 3000 is a heavy-duty engine lathe designed for machining large shafts, hydraulic cylinders, rollers, flanges, and oversized industrial components. Featuring a 30" swing over bed, 118.11" between centers, and a rigid 15.75" wide bed, the LA760 × 3000 delivers excellent rigidity and cutting performance for heavy manufacturing, repair facilities, oilfield service, mining, and fabrication shops.

Equipped with a 12-speed geared headstock, precision feed gearbox, and full metric and imperial threading capability, the LA760 × 3000 is built for reliable roughing and precision finishing of large workpieces.

Specifications

Capacity

Swing over bed: 760 mm (30")
Swing over cross slide: 560 mm (22")
Swing in gap: 1015 mm (39.97")
Gap width in front of face plate: 270 mm (10.63")
Distance between centers: 3000 mm (118.11")
Bed width: 400 mm (15.75")
Top slide travel: 190 mm (7.5")
Center height from base: 1182.5 mm (46.5")

Spindle

Spindle bore: 86 mm (3.38") or 104 mm (4.09")
Spindle nose: ASA A1-8 (D1-8) or ASA A1-11 (D1-11)
Internal spindle taper: MT7 / MT5
Spindle speed: 13–1200 RPM (optional 8–800 RPM)
Speed ranges: 12 Steps

Threading & Feed

Metric threads: 0.2–14 mm (39 ranges)
Imperial threads: 2–72 TPI (44 ranges) or 1–36 TPI (44 ranges)
Longitudinal feed: 0.035–0.98 mm/rev (Imperial lead screw) or 0.037–1.04 mm/rev (Metric lead screw)
Cross feed: 50% of longitudinal feed
Feed ranges: 36 Steps
Lead screw: Ø45 mm (1.75") × 4 TPI or 6 mm

Tailstock

Tailstock taper: MT5
Quill diameter: 75 mm (2.94")
Quill stroke: 178 mm (7")

Motor

Main motor: 10 HP / 4P
Coolant pump motor: 1/8 HP

General

Machine weight: 5500 kg (12,125 lbs)
Machine dimensions: 4700 × 1300 × 1900 mm (185 × 51 × 75")

Standard Features

12-Speed Geared Headstock
Power Longitudinal & Cross Feeds
Metric & Imperial Threading
Coolant System
Hardened & Ground Bed Ways
Leveling Screws
Dead Center
Service Kit

Optional Accessories

Digital Readout (DRO)
4-Jaw Independent Chuck
Steady Rest
Follow Rest
Taper Turning Attachment
Rear Splash Guard
LED Work Light
